Case Blog - Biomedical Research (2022) Volume 33, Issue 2

Arterial thrombosis, the unfairly forgotten actor in COVID-19: A case series.

Sergio Ramos Cillan1#, Laura Solan Blanco1*#, Marta Tomas Mallebrera2, Ana B. Arribas Díaz3, Javier Cornago Navascues1, José Luis Lopez Lorenzo1, María Pilar Llamas Sillero1,4

1Department of Hematology, Fundación Jiménez Díaz University Hospital, Madrid, Spain

2Department of Radiology, Fundación Jiménez Díaz University Hospital, Madrid, Spain

3Department of Vascular Surgery, Fundación Jiménez Díaz University Hospital, Madrid, Spain

4Health Research, Institute of the Jiménez Díaz Foundation (IIS-FJD), UAM, Madrid, Spain

#contributed equally to this work.

Corresponding Author:
Laura Solan Blanco
Department of Hematology
Fundación Jiménez Díaz University Hospital
Madrid
Spain

Accepted date: February 17, 2022

Visit for more related articles at Biomedical Research

Abstract

Background: It is known that patients with COVID-19 are at increased risk of thrombosis. Although COVID-19 infection primarily affects the lower respiratory tract system, emerging reports suggest direct and indirect cardiovascular complications. However, the key mechanisms under thrombosis development at great arterial vessels are still unclear.

Case presentation: We report the cases of 4 patients who were admitted to our hospital and suffered from arterial thrombotic complications. All of them were older than 60 years and only 1 did not have cardiovascular risk factors. It should be noted that days prior to the diagnosis of arterial thrombosis, 3 of the 4 patients were under anticoagulant treatment. It is also interesting that in contrast to already known typical microvascular locations, our patients suffered from large arterial vessels thrombosis. Furthermore, none of them would present with severe respiratory symptoms.

Conclusion: The underlying mechanism of COVID-19-associated arterial thrombosis remains unclear and might be independent of the cytokine storm that occurs in patients with COVID-19-associated venous thrombosis. Also, the role of anti-platelets agents as prophylactic treatment in high-risk patients remains unclear. Multicenter clinical trials are necessary to clarify these issues.

Keywords

COVID-19, Arterial thrombosis, Right ventricle thrombus, Acetylsalicylic acid, Thromboprophylaxis.

Abbreviations

A: Amputation; AF: Atrial Fibrillation; ALI: Acute Limb Ischemia; AML: Acute Myeloid Leukemia; Ao: aorta; ARDS: Acute Respiratory Distress Syndrome; ASA: Acetylsalicylic Acid; BAB: Bifemoral Axillary Bypass; CF: Common Femoral; CI: Common Iliac; COVID-19: Coronavirus Disease 2019; CTA: Computed Tomographic Angiography; CV: Cardiovascular; HIV: Human Immunodeficiency Viruses; HT: hypertension-13544.html'>Hypertension; IAo: Infrarenal aorta; LDH: Lactate Dehydrogenase; LF: Left Femoral; LFi: Local Fibrinolysis; LMWH: Low- Molecular-Weight-Heparin; n a: not available; n d: new diagnosis; PCR: Protein-Chain-Reaction; PT: Prothrombin Time; r: remission; RCP: Reactive-C protein; RP: Right Popliteal; RV: Right Ventricle; SARS-CoV2: Severe Acute Respiratory Syndrome Coronavirus 2; TE: Thrombectomy; TTE: Transthoracic Echocardiogram; VTE: Venous Thromboembolism.

Background

Patients with Coronavirus Disease-2019 (COVID-19) are at increased risk for venous and arterial thrombosis. The inflammatory response and the dysfunction of the vascular endothelium seen in the context of COVID-19 infection may predispose to coagulation disorders and other deleterious complications. It is well known that endothelial injury plays a significant role in COVID-19 related comorbidities such as hypertension, obesity and diabetes. Given the rapidly growing pandemic lived worldwide in the last months; there is an urgent need to measure the rate of thrombotic manifestations associated to COVID-19 and to analyze its impact on survival.

Although COVID-19 infection primarily affects the lower respiratory tract system, emerging reports suggest direct and indirect cardiovascular complications. We report the cases of 4 patients who were admitted to our hospital.

None of them presented with severe respiratory symptoms and 3 out of 4 were under antithrombotic treatment. However, all of them suffered from arterial thrombotic complications and needed urgent surgery. Moreover, one of them presented with a right ventricle thrombus, a very rare complication, even in patients with severe pneumonia.

Multiple studies report that microvascular thrombotic and inflammatory processes may play a role in exacerbating Acute Respiratory Distress Syndrome (ARDS) and extrapulmonary events in patients suffering from COVID-19, but key mechanisms in large arterial vessels thrombosis is not clear yet.

Case Presentation

Characteristics of the four patients are detailed in Table 1. As described below, two of them had a history of cancer, and likewise three out of four patients had cardiovascular risk factors. Despite confirming concomitant infection with COVID-19 in all patients, none of them required mechanical ventilation during their hospitalization.

Baseline characteristics Case 1 Case 2 Case 3 Case4
Age (years)
Gender
CV disease risk factors
63
male
none
63
female
diabetes, smoking
66
male
diabetes, HT
85
female
HT
Previous cancer    AML(nd), bladder(r) cervical(r) no no
Other background none AF, stroke, HIV none AF
COVID-19 infection
Diagnostic test PCR PCR PCR PCR
ARDS no no no no
Pneumonia yes yes no yes
Treatment
Low flow O2 therapy yes no no yes
Mechanical ventilation no no no no
Remdesivir yes no no no
Corticoids yes no no yes
Anticoagulation prophylactic therapeutic no therapeutic
Cyclosporine no no no no
Thrombus localization IAo/CI/LF/RP/RV IAo CF IAo/CI
Imaging exam CTA/TTE CTA CTA CTA
Days between infection and thrombus diagnosis 23 20 0 25
Treatment TE + BAB + A BAB LFi + TE + A TE
VTE associated no no no no
Status dead alive alive alive

Table 1: Demographic and clinical characteristics at the time of the thrombotic event.



Case 1 Case 2 Case 3 Case 4
  Complete blood count
   Hemoglobin (g/dL) 7.2 14.4 12.8 14.8
   Platelet count (x103/mm3) 37 215 296 174
   White cells (x103/mm3) 5,490 12,800 14,170 16,740
   Lymphocytes (x103/mm3) 4,800 1,600 1,000 1,200
   Neutrophils (x103/mm3) 400 10,200 12,600 14,600
Coagulation test
   PT (sec) 26 14 n a 11.4
   INR 2.2 1.24 1.34 1.06
   aPTT (sec) 24.1 25.3 28.5 28.2
   D-dimer (ng/mL) 38,000 7,097 2,500 1,517
   Fibrinogen (mg/dL) 824 656 1,020 912
RCP (mg/dL) 41 5.2 24.3 6.1
Ferritin (ng/mL) 3,350 580 1,952 n a
Antiphospholipid antibodies no no no n a
Factor V Leiden  no no no n a
Creatinine (mg/dL) 0.9 1.47 1 0.4
LDH (U/L) 4,400 980 495 274
Bilirubin (mg/dL) 0.3 1 0.9 n a

Table 2: Laboratory findings at the time of the thrombotic event.

Case 1, a 63 years old man, was admitted to our hospital due to asthenia, low oxygen saturation and a previous diagnosis of COVID-19 infection, with pulmonary infiltrates in chest X-ray. He was also diagnosed with Acute Myeloid Leukemia (AML) when cytologist checked his blood smear. Before starting the treatment for his AML and due to the fact that his peripheral blood values were stable, treatment against COVID19 was started. He required lowflow nasal cannula oxygen therapy, intermediate doses of corticosteroids, intravenous remdesivir (200 mg the first day and 100 mg for four more days) and Low-Molecular- Weight Heparin (LMWH) as thromboprophylaxis until platelet count dropped below 30,000 per mm3. The initial response to treatment was satisfactory, and oxygen therapy could be suspended. Induction chemotherapy for AML with cytarabine and idarubicin was then started. Two days after removing heparin the patient presented with loss of strength and right lower limb pain. It was very light at the beginning but disabling just 48 hours later. A Computed Tomographic Angiography (CTA) was then requested. Large filling defects were identified in the descending infrarenal abdominal aorta and both common iliac arteries. Blood flow at left femoral and right popliteal arteries was restricted too. Many filling defects causing focus of ischemia in both kidneys were seen in renal polar arteries. Moreover, filling defects were seen in splenic parenchyma. Findings, which are shown in Figure 1, were unlikely related to an embolic origin. A thrombus of uncertain origin was also found in his right ventricle. With the diagnosis of Acute Limb Ischemia (ALI), a thrombectomy and a bifemoral axillary bypass was established. The patient was transferred to the intensive care unit. Two days later he presented with muscular necrosis and collateral revascularization and right below knee amputation was performed. At 48 hours the patient suffered from febrile neutropenia, probably secondary to his immunosuppression and died. No signs of infection were found at the amputation stump.

Figure 1: A) Computed Tomography Angiography (CTA) three-dimensional image shows extensive thrombosis of the infrarenal aorta with extension through common iliac arteries. Axial contrast-enhanced CT images show a patent/ permeable suprarenal aorta (arrow in I), and an occlusive infrarenal aortic filling defect (arrow in II) extended through common iliac arteries (arrow in III) with repermeabilization of the contrast pool at the level of femoral arteries (arrow in IV). It is remarkable that there is not a significant pre-existing aortic atherosclerosis. A contrast-enhanced CT scan also reveals perfusion defects (*) in the spleen (I) and in the left kidney (II) consistent with infarcts. B) CT Angiography (CTA) three-dimensional image of the lower extremities shows occlusion of the right popliteal artery (arrow). There is no evidence of arterial perfusion below the right knee. C) Axial CT image demonstrates a thrombus (black arrow) in the right ventricle and in the right hepatic vein (black arrow) in D.

Case 2, a 63 years old woman, under acenocoumarol treatment (within the desired range) due to Atrial Fibrillation (AF) was admitted in our hospital due to dyspnea associated to a previous diagnosis of COVID19. She would not have required previous oxygen support or any other invasive treatment other than thromboprophylaxis and steroids. She presented loss of strength and sensitivity as well as urinary sphincter’s control. Acute thrombosis of the infrarenal aorta was diagnosed using CTA. A bifemoral axillary bypass was established with successful results. Hospital discharge took place some days later. Main radiological findings are shown in Figure 2.

Figure 2: Computed Tomography Angiography (CTA) three-dimensional image and axial contrast-enhanced CT images shows extensive thrombosis of the infrarenal aorta (in II) with extension through common internal and external iliac arteries (arrows in III) with repermeabilization in the common femoral arteries (arrows in IV). A contrast-enhanced CT scan also reveals perfusion defects (*) in the spleen and in both kidneys.

Case 3, a 66 years old man with a recent ankle arthrodesis surgery in his right foot took advice at emergency department due to a 4 days clinical picture of edema and wound suppuration associated to anosmia and ageusia. He was not under anticoagulant treatment and COVID-19 infection was unexpectedly confirmed by RT-PCR test. He did never require oxygen support. He did also suffered loss of sensitivity and strength with lack of distal palpable pulse in his right ankle. A CTA, which we shown in Figure 3, confirmed clinical suspicions of acute femoral ischemia. Local fibrinolysis and thrombectomy was performed without successful results, finally needing to have his right leg amputated.

Figure 3: Computed Tomography Angiography (CTA) three-dimensional image (A,B) shows narrowing of the lumen and occlusion of the right superficial femoral artery (arrow without opacification of the distal vessels. (*, ankle arthrodesis). Axial contrast-enhanced CT images (I) show an acute occlusive thrombus in the right superficial femoral artery (arrow).

Case 4, a 85 years old woman, under dabigatran treatment due to AF was admitted at our hospital due to severe pain starting at her right gluteal region and reaching down to the knee. She presented loss of strength and sensitivity as well as coldness and paleness. She referred a similar clinical picture in the left leg a couple days before. It had been solved spontaneously. A CTA was requested and large filling defects were identified in infrarenal abdominal aorta and both common iliac arteries. Superior mesenteric, celiac and renal arteries were permeable. Moreover she had been hospitalized until 12 days before due to bilateral pneumonia secondary to SARS-CoV2. She did not present with a severe respiratory syndrome and did not require mechanical ventilation. Figure 4 demonstrates the main filling defects at aortic bifurcation and the occlusion of the common iliac arteries. Urgent surgery, bilateral transfemoral embolectomy, took place in order to remove the thrombi. After achieving satisfactory clinical results, she was discharged from hospital a few days later.

Figure 4: A) Computed Tomography Angiography (CTA) three-dimensional image demonstrates a thrombotic obliteration of the aortic bifurcation with extension through common iliac arteries. Axial contrast-enhanced CT images show non-occlusive arterial thrombi in the intrarenal aorta above the bifurcation (arrow in I) and the occlusion of the common iliac arteries (arrows in III).

Table 2 shows main analytic parameters at time of arterial thrombosis diagnosis. Except for case 1, who was under chemotherapy because of his AML, blood count was normal in all cases. Moreover, all of them presented with elevated D-dimer levels. However, thrombophilia studies were performed in three of them and none showed positivity for antiphospholipid antibodies or factor V Leiden mutation. Other parameters related to prothrombotic status such as Prothrombin Time (PT) or S and C proteins were normal.

One last aspect we would like to point out is that except for case 3, in which macroscopic findings compatible with atherosclerosis were found, the other 3 patients showed healthy arteries, with no evidence of pre-existing vessel lesions or atheroma surrounding the thrombi.

Discussion

An increase in morbidity and mortality due to thromboembolic events has been shown in patients suffering from COVID-19 infection [1]. The big rate of Venous Thromboembolism (VTE) has been widely highlighted, but few studies are focused on systemic arterial embolism [2]. There is a growing interest in determining the risk factors involved in the development of thrombosis [3].

On the one hand, different working groups have reported the relationship between age, gender, cardiovascular disease or cancer history and severity of SARS-CoV2 infection. We present herein two men and two women, whose median age was 69 years old.

Two of the most important retrospective studies taken place in Wuhan, China, showed a clear predominance of men over women in terms of severity and mortality as well as poorer outcomes in the oldest versus the younger patients [4,5]. Other cardiovascular risk factors such as diabetes, overweight, smoking and hypertension have been established as predictors of mortality due to COVID-19 [4,6]. It is also known that the risk of severe illness due to SARS-CoV2 infection is higher in patients with cancer history [7]. The cases we present support most of the outcomes previously described [4,5,7].

On the other hand, Zhang et al. have notified that thrombosis is caused by hypercoagulability due to antiphospholipid antibodies that can arise transiently in patients with critical illness and infections [8]. However, none of the cases that we present here showed positivity in these tests. Moreover, Malentacchi et al. have reported cases of simultaneous occurrence of VTE and arterial thrombosis [9], but none of the patients we present here evolved in this way.

Furthermore, severity of respiratory symptoms and rate of thrombosis also seem to show some mismatch. To note, in contrast to the few studies taken place in our working environment, none of the patients we present with concomitant COVID-19 infection required invasive oxygen therapy. This observation makes an important difference in contrast to other cases reported, which show clear correlation [10,11].

Additionally, we would like to emphasize that three of the patients we present developed arterial thrombosis independently of the use of antithrombotic treatment [11]. Two of our patients were receiving properly full (therapeutic) dose of anticoagulant therapy due to AF and another one had been receiving LMWH as prophylaxis until platelet count decreased below 30,000/mm3. Due to the above, the prophylactic use of low doses of Acetylsalicylic Acid (ASA) has been discussed by different groups. It is well known the anti-inflammatory and antithrombotic effect of ASA [12]. In addition to these effects of ASA, in vitro and experimental models support its capacity to reduce replication, propagation, and infectivity of several RNA-enveloped viruses, including human CoV-229E and MERS-CoV [13]. Thus, different working groups advocate the widespread use of ASA prophylactically in COVID19 infection [13,14]. Chow et al. described in a large cohort study of 412 COVID-19 infected patients that the use of ASA was independently associated with a lower risk of mechanical ventilation, ICU admission, and inhospital mortality [15]. Conversely, Sahai et al. hold that the use of traditional antiplatelet agents may not protect against thrombotic events or mortality in COVID-19 infection. When comparing two study groups, they find that ASA therapy was associated with an increased risk of thrombotic stroke (3.6% vs 0.40%, P=0.036) [16].

Platelets have a wide range of critical functions and mechanisms of thrombosis in COVID-19 deserve further investigation. Drug trials are necessary to determine the real role ASA could play in these patients.

One more aspect we would like to point out is the unexpected location of the thrombi. Studies that report arterial thrombosis describe the main affected vascular territories. Limbs and mesenteric ischemia, as well as cerebral territories were the most frequently affected areas [11,17,18]. However, we present herein the concomitant finding of a right ventricle thrombus in one of the four patients. This special vascular bed has not been widely reported yet [19-21]. In most of the cases that have been described before, Transthoracic Echocardiogram (TTE) was obtained given the severity of hypoxemia and hemodynamic instability of patients [22-24]. As far as we know, this is the first case in which right ventricle thrombus was found in a patient with no invasive oxygen therapy or hemodynamic instability. It was an unexpected finding seen in the upper part of CTA performed to diagnose the abdominal aortic thrombosis. Given that the TTE is a minimally invasive test, it could be performed routinely in patients with COVID-19 infection and arterial thrombosis, in order to anticipate severe complications, such as ventricular thrombosis.

Finally, we would like to emphasize the poorly known mechanisms underlying microvascular thrombotic and inflammatory processes seen in patients suffering from COVID-19. Multiple studies have found that they may play an important role in exacerbating ADRS and extrapulmonary events in these patients [3,25-28]. These deleterious complications likely result from dysfunction of the vascular endothelium [29]. Its dysregulation leads to vasoconstriction, hyperinflammation, vascular leakage, thrombosis and improper antiviral immune response. Moreover, endothelial dysregulation is a well stablished actor in reported COVID-19 comorbidities such as hypertension, obesity or diabetes [30-33]. In spite of the fact that abnormal coagulation and inflammation parameters provide evidence for endothelium dysregulation in severe COVID-19 patients, the pathophysiological mechanisms underlying this situation still require further clarification [34,35]. It seems clear, however, that SARSCoV2 may use two related pathways; either directly through endothelial cell infection or indirectly through the infection of other susceptible cell types, which cause hyperinflammation and aberrant antiviral responses [25,27]. Reports of microangiopathic complications in severe COVID-19 support a role for immunothrombosis in viral pathogenesis. SARS-CoV2 was recently found to promote pro-inflammatory complement activation in association with endothelial damage in severe COVID-19 [36,37]. This may promote the development of complement-suppressing therapeutics aimed at decreasing hyperinflammation in severe COVID-19 [38].

Conclusion

In conclusion, COVID-19 infection may predispose patients to an increased risk of thrombotic complications through different pathophysiological mechanisms, such as inflammation, immobilization, endothelial dysfunction, and a hypercoagulable state, all of them, still in need of deeper investigation. Further studies should focus on the rate and association of thromboembolic events and SARSCoV2 infection and identifying the patients at higher risk for arterial thrombosis to determine the best preventive maneuvers.

Declarations

Ethics Approval and Consent to Participate

Ethical approval for this study has been sought. It has been approved by Fundación Jiménez Díaz University Hospital research ethics committee and has been performed in accordance with the ethical standards as laid down in the 1964 Declaration of Helsinki and its later amendments.

Consent for Publication

Informed consent was obtained from all individual participants included in the study who were alive at that moment, according to the research ethics committee instructions.

Availability of Data and Materials

Not applicable.

Competing Interests

The authors declare that they have no competing interests.

Funding

Not applicable.

Author’s Contributions

SR and LS contributed equally to this work. The authors provided a diverse patient care among different institutions.

Conception and design: SR, LS and PL.

Data collection: SR, LS and MT.

Data analysis: SR, LS, AR and PL.

Manuscript drafting: SR and LS.

Critical manuscript revision: All authors.

Final approval of the manuscript: All authors.

Acknowledgement

Authors expressed great gratitude to the patient support for our case report and to the Hematology and Radiology Department of Fundación Jiménez Díaz University Hospital in Madrid, Spain, for supporting this work.
